Usha Filter Fan Filter Unit (FFU) is a self-contained air filtration device commonly used in cleanrooms, laboratories, data centres, and other controlled environments. It is designed to provide high-quality, filtered air to maintain the required cleanliness level in the space.
The main components of a Fan Filter Unit include:
- Fan
- HEPA or ULPA Filter:
- Housing
- Inlet Grille
- Outlet Vent
Technical Specifications
| Housing Material - | Stainless Steel, Aluminium |
| Model - | EC |
| Air Velocity - | 0.3-0.5 m/s |
| Total Static Pressure - | 250 Pa |
| Motor - | DC Brushless |
| Airflow Control - | 3 Speeds / Stepless Speed Monitored Type |
| Filter Efficiency - | As Per EN1822 Grade H14 / U15 |
| Filter Frame - | Aluminium |
| Power supply - | 220V AC/ 1P / 50Hz |
| Noise Level - | (DBA): < 60 |
| Optional - | Pre Filter, Collar, Insulation, Hanger, Electrical Cable |
| FFU Available in size – | 610 X 610 X 275 mm 1220 X 610 X 275 mm |
